Design of Environmental Hardware in Car Alternator Testing System

Abstract:

In an automobile, a stable and durable alternator is extremely important. Based on the basic characteristics of the alternators now on the mainstream market, the hardware simulation method was used to build a simulated “car engine-alternator-auto load-the external environment hardware environment” system. High and low temperature humidity test chamber simulates the vehicle internal environment and the inverter driving power frequency conversion is used to simulate motor car engine power system. It uses fixtures, belts, and pulleys to simulate the connection of the engine to the alternator. In addition it uses electronic load cases to simulate automobile electric power consumption with all kinds of current, voltage, speed signal components to provide feedback signals based on the testing system of alternator to make comparisons. The testing system is designed by analyzing and optimizing the structural mechanics of the whole system according to the requirement of the hardware system layout. For each part of the system factors of design were considered included shape, size, material selection process and heat treatment. Parts and detailed drawings were prepared and later sent for fabrication. The tests indicate that hardware alternator testing system has no major defects that can prevent it from being developed for commercial use.

References

[1] The People's Republic of China automotive industry standard QC / T 729-2005, automobile alternator technical conditions (Automotive alternator technical specification) [S]. National Development and Reform Commission released 2005. 2. 14 release / 2005. 7. 1 implementation.

[2] X.S. Cai, L.Y. Liu: Zero Frequency Conversion Technology from the Fabric Easy [S]. Posts & Telecom Press, Beijing(2009).

[3] S.L. Wu, Y.J. Min, X. Mei: LabVIEW-based AC waveform generator fault diagnosis system [J]. Science and Technology Information (Science • Teaching and Research) Vol. 25-103 (2007), p.91.

[4] H.B. Wang: Aviation Integrated Test System Generator [D]. Xi'an University of Technology, Xi'an(2008).

[5] X.L. Shen: Based on LabVIEW for Automotive Alternator Test Bed Development. South China University of Technology(2009).

[6] L.J. Kong, C.L. Zhang: Based on Mechanical design of an integrated curriculum [M]. Beijing Institute of Technology Press, Beijing(2004).

[7] F.T. Zhao, Sol. Automotive electrical equipment construction and maintenance [S]. China Machine Press, Beijing(2007).

[8] G. Delos, D. Helton: Migration of Power train Electronics to On-Engine and On-Transmission [J]. SAE040426(1999).

[9] China Machinery Industry Education Association: Automotive electrical and electronic equipment [M]. Mechanical Industry Press, Beijing(2003), pp.19-38.
