Reverse Design for Wine Cushioning Package of Honeycomb Paper Core

Abstract:

Based on the background of cushioning package design for the wine bottles, the analysis on the cushioning properties of honeycomb paper core is presented. The reverse design method based on the function relationship of cushioning package is proposed, to make the cushioning structure design and cushioning dimension design as well as the buffering pad checkout, including strength check, deflection check and creep deformation check to make sure design meets the requirements. The function relation of the maximum acceleration and static stress between arbitrary dropping height and thickness of cushion is obtained. The reverse design method can obtain any curve of any dropping height and any cushioning thickness through several experimental tests. The flexibility, what is more important is that the method can greatly reduce test time, saves the cost of enterprises and technology research & development. The method provides a new way to the cushioning package design.

You might also be interested in these eBooks

Applied Research and Engineering Solutions in Industry

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 312)

Pages:

200-204

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.312.200

Citation:

Cite this paper

Online since:

February 2013

Authors:

Jian Wu, Yong Long Wang, Le Yang Chen, Yan Ping Du, Li Yang

Keywords:

Buffering Material, Cushioning Package, Honeycomb Paper Core, Honeycomb Structure, Reverse Design, Wine Package

Export:

RIS, BibTeX

Price:

Permissions:

Request Permissions

Сopyright:

Citation:

References

[1] C.Liu and J.Liu. stress energy method in calculating the maximum acceleration - packaging materials static stress curves with respect to the application analysis . Packaging engineering,2011,32(01):74-75(In Chinese)

Google Scholar

[2] J.Wu, Y.L. Wang, G.M. Zhang, Y.Zhang and X.Z.He. The optimal stretching angle of honeycomb paper core based on the fourth strength theory. Packaging engineering,2012,9(1)

Google Scholar

[3] X.Y. Wang and H.N. Wang. Research on the cushioning performance of honeycomb paperboard. China Packaging Industry, 2010,(11):28-30(In Chinese)

Google Scholar

[4] Y.F. Guo and H.Jing. Dynamic cushioning property of honeycomb paperboard test analysis . Packaging engineering,2002,23(6):6-8,14(In Chinese)

Google Scholar

[5] J.Wu, Y.L. Wang, Y.Zhang and G.M. Zhang. The optimal stretching angle of honeycomb paper core based on the fourth strength theory. Applied Mechanics and Materials,2012 International Conference on Industrial Design and Processes. 2012.10

DOI: 10.4028/www.scientific.net/amm.288.256

Google Scholar

[6] G.M. Zhang and Y.L.Hu. Different specifications of the cushioning performance of honeycomb paperboard research. Packaging engineering, 2008,29(10):77-79(In Chinese)

Google Scholar
