Enhancement of Welded Joints Productivity Effect of Welding Position on Fatigue Strength

Abstract:

Welded structures are frequently used in today’s metal industry. Since fatigue is still one major reason of failures, investigation in this field is of interest to engineers. In this study experimental methods are employed to perform a fatigue evaluation concerning local weld geometry. The emphasis was on quantifying the weld toe radius as a feature in quantification of weld quality. Three different welding positions which have been led to different toe radii were analyzed. Each batch contained 12 specimens manufactured in cruciform joint and has been tested in non-load carrying status. Finally, the results of tests were compiled in Wöhler (S-N) curve and compared to reference curves introduced by IIW (International Institute of Welding). Results of this study show that local weld geometry has remarkable influence on strength of welded structures. It can be concluded that specimens with larger toe radii had more fatigue strength – as it was expected from the theory.

• Periodical: Applied Mechanics and Materials (Volumes 110-116)
• Pages: 202-209
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.110-116.202
• Online since: October 2011
• Authors: Mahdi Kazemi Hatami, Amir Masoud Amini, Kamran Fallahi
• Keywords: Fatigue, S-N Curve, Weld Geometry

References

[1] Samuelsson J., Fatigue design of vehicle components methodology and applications, Dept. of Aeronautical Structures and Materials, Report no. 88-23, Doctoral Thesis, The Royal Institute of Technology, Stockholm, (1988).

[2] Lopez Martinez L., Korsgren P., Characterization of initial defect distribution and weld geometry in welded fatigue test specimens, Fatigue under Spectrum Loading and Corrosive Environment, pp.3-21, Warley, UK, EMAS, (1993).

[3] Signes, E. G et al, Factors affecting the fatigue strength of welded high strenght steels, Brit. Welding Journal., 14(3), pp.108-116, (1967).

[4] Jakobovskii V. V and Valteris I. I, Geometrical parameters of butt and fillet welds and their influence on the welded joint fatigue life, IIW Doc XIII-1326-89, (1989).

[5] Jonsson B., Barsoum Z. and Ghavi Bazou A., Influence from weld position on fillet weld quality, IIW doc. XIII-2273-09.

[6] Mahdi K. Hatami, Fatigue Assessment of Cruciform Joints welded in Different positions, M. Sc. thesis, KTH University, Stockholm, Sweden, (2009).

[7] Radaj D., Sonsino C. M., Fatigue assessment of welded joints by local approaches, Abington Publishing, Cambridge, (1998).

DOI: 10.1533/9781845691882

[8] Casavola C. and Pappalettere C., Discussion on local approaches for the fatigue design of welded joints, International Journal of Fatigue, Vol 31, p.41– 49, (2009).

DOI: 10.1016/j.ijfatigue.2008.07.017

[9] Hobbacher A., Recommendation for fatigue design of welded joints and components, IIW doc. XIII-2151-07 / XV-1254-07.

[10] Radaj D., Sonsino C. M., Design and analysis of fatigue resistant welded structures, Abington Publishing, Cambridge, (1990).

[11] Nykänen T., Marquis G. and Björk T., Effect of weld geometry on the fatigue strength of fillet welded cruciform joints, Proceedings of the International Symposium on Integrated Design and Manufacturing of Welded Structures, March 13-14, 2007, Eskilstuna, Sweden, ISBN 978-952-214-363-1 ISSN 1459-2924.

DOI: 10.1016/j.engfracmech.2006.05.017

[12] Nykänen T., Marquis G. and Björk T., Fatigue analysis of non-load-carrying fillet welded cruciform joints, Engineering Fracture Analysis, Volume 74, Issue 3, pp.399-415, February (2007).

DOI: 10.1016/j.engfracmech.2006.05.017
