Generating Characteristics of a Cantilever-Type Unimorph Piezoelectric Generator Depending on the Material and Mass

Abstract:

Structure of a cantilever-type unimorph piezoelectric generator was proposed and designed so as to allow the generator to resonate at frequencies lower than commercial frequencies. This generator is capable of generating amount of voltage its despite low frequency and simple fabrication that result from its simple structure. In this paper, the resonance characteristics of the generator depending on significant parameters were determined through a modal analysis and the influence of each parameter was analyzed to define each its level of sensitivity on the high output characteristics using ANSYS, a FEM program. The generators resonated at frequencies lower than 60 [Hz], as determined through the FEM results. The generating characteristics were then defined by implementing vibration experiment and comparing the results with those from the analysis. The resonance frequency and output power depending on changes in the mass and material were determined by the analysis.

• Periodical: Applied Mechanics and Materials (Volumes 110-116)
• Pages: 217-224
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.110-116.217
• Online since: October 2011
• Authors: C.H. Park, J.W. Kim, S.S. Jeong, M.H. Kim, T.G. Park, H.H. Chong
• Keywords: Cantilever, FEM Analysis, Low Frequency Driving, Piezoelectric Generator, Unimorph

References

[1] J. L. Gonzalez, Antonio Rubio and Francesc Moll, Human Powered Piezoelectric Batteries to Supply Power to Wearable Electronic Devices, International Journal of the Society of Materials Engineering for Resource, p.7, (2001).

[2] H.W. Kim, Phd Thesis, Impedance Adaptation Methods of The Piezoelectric Energy Harvesting, p.27, (2006).

[3] H. I. Jun, Design and Fabrication of Piezoelectric Generator using Piezoelectric ceramics, Journal of the Korean Institute of Electrical and Electronic Material Engineers, Vol. 9, pp.315-316, (2008).

[4] J. Kymissis, C. Kendall, J. Paradiso, N. Gershendeld, parasitic Power Harvesting in Shoes, Second IEEE International Conference on Wearable Computing, p.34, (1998).

DOI: 10.1109/iswc.1998.729539

[5] T.G. Park, B.J. Kim, M.H. Kim, and K. Uchino, Characteristics of the first longitudinal-fourth bending mode linear ultrasonic motors, J.J.A.P., vol. 41, 2002, pp.7139-7143.

DOI: 10.1143/jjap.41.7139

[6] J. Hu, A Study on The Rectangular Bar Shaped Multilayer Piezoelectric Transformer using Length Extensional Vibration Mode, J.J. Applied Physics, May, Vol. 38, No. 5B, pp.3208-3212, (1999).

DOI: 10.1143/jjap.38.3208

[7] K. Uchino, Piezoelectric Actuators and ultrasonic motors, Kluwer Academic Publishers, pp.129-138, (1997).

[8] Phillips Components, Piezo Ceramic Products, Technical information, pp.3-10, (2000).

[9] ANSYS, Inc. ANSYS, Theory Manual, all.

[10] S. S. Rao, Mechanical Vibrations, Addison-Wesley Publishing Company, Inc., pp.427-437, (1990).
